BB-719: How to Test Nickel-Based Batteries for Aging and State of Health

Nickel-cadmium (NiCd) and nickel-metal hydride (NiMH) batteries can lose usable capacity as they age, while their internal resistance may increase. In many cells, resistance remains relatively low during the earlier part of service life and rises more noticeably as the cell approaches end of life. This pattern makes resistance a useful warning signal, but it does not provide a dependable percentage-based state-of-health result by itself.

A resistance measurement is best treated as a quick screening method. A more useful assessment combines electrical measurements with capacity, self-discharge, charging behavior, and discharge performance. Pack construction and differences between individual cells must also be considered, because a pack-level result can hide a weak cell or include resistance from welds, tabs, connectors, and other mechanical links.

How Aging Changes Nickel-Battery Resistance and Capacity

Both NiCd and NiMH batteries can show increasing internal resistance as they age and lose capacity. Internal resistance limits the voltage available under load and contributes to voltage sag, heat generation, and reduced power delivery. Capacity loss, by contrast, reduces the amount of charge the battery can deliver during a controlled discharge. These are related effects, but they are not the same measurement.

In a simplified aging pattern, a nickel cell may retain relatively stable resistance during an earlier period of its life. Resistance can then increase more rapidly as degradation becomes advanced. The exact pattern is not universal. It depends on the nickel chemistry, cell size and construction, operating load, temperature, charge history, depth of discharge, and the test method used.

This distinction is important when interpreting a resistance reading:

  • A high resistance can indicate an aged, damaged, poorly charged, or unusually cold cell.
  • A low resistance does not prove that the cell has its rated capacity.
  • A resistance trend measured under consistent conditions is generally more useful than one isolated reading.
  • Resistance can provide an end-of-life warning without identifying the battery’s precise remaining state of health.

A conventional capacity test remains the more direct way to determine how much energy or charge a battery can deliver under defined conditions. Resistance testing is faster and can help identify batteries that need closer examination, but it should not be used as a complete health evaluation. Temperature, state of charge, contact resistance, measurement frequency, and the amount and duration of the test current can all affect the result.

For a battery pack, the measurement also represents the combined electrical behavior of the cells and the pack hardware. This makes it especially important to compare results with reference data for the same battery type and test conditions rather than applying a universal resistance limit.

Multi-Parameter Rapid Testing for State of Health

A rapid diagnostic approach can provide a broader assessment by combining several battery characteristics instead of relying on internal resistance alone. The QuickTest concept described for nickel-based batteries is an example of this type of approach. Its purpose is to combine multiple observations and produce a state-of-health estimate expressed as a percentage.

The six input categories associated with this concept are:

  1. Capacity — the amount of charge the battery can deliver during a defined test.
  2. Internal resistance — the opposition to current flow, including the effects captured by the selected measurement method.
  3. Self-discharge — the rate at which the battery loses charge while standing unused.
  4. Charge acceptance — how effectively the battery accepts charge under the applicable charging conditions.
  5. Discharge capability — the ability to deliver current or power during use.
  6. Electrolyte mobility — an indicator associated with the movement or condition of the electrolyte within the cell.

Not every input in a multi-parameter system must be obtained through a separate direct test. Some values may be measured, while others may be inferred from the battery’s electrical response or from relationships established during characterization. The exact implementation, instrumentation, and validation procedure determine what the system actually measures and what it estimates.

The central principle is that no single electrical value describes all aspects of battery aging. Two cells can have similar resistance but different capacity or self-discharge behavior. Conversely, a cell with a moderate resistance reading may still have a problem that appears more clearly during charging or controlled discharge.

To interpret the measurements, a diagnostic system needs battery-specific reference information. This may take the form of lookup tables, reference matrices, characteristic curves, or an equivalent model. The reference information should account for the battery chemistry and, where necessary, its design, rated capacity, operating condition, and intended use. A result is meaningful only when the test system has an appropriate basis for comparing the measured behavior.

The QuickTest name should therefore be understood here as a diagnostic concept described in the source material, not as a claim about current availability, supported battery models, measurement accuracy, or manufacturer service. Those details require confirmation from the current equipment documentation and validation data.

Conceptual battery diagnostic flow showing capacity, resistance, self-discharge, charging, and discharge measurements being combined into a state-of-health estimate
A multi-parameter diagnostic combines several battery characteristics with reference data to estimate nickel-battery state of health.

Source: Battery University

How Combined Battery Measurements Are Interpreted

In a multi-parameter diagnostic, the measured data is sent to a controller, instrument, or analysis system. The raw values are then converted into a form that allows unlike quantities to be compared. For example, capacity, resistance, and self-discharge have different units and scales, so they cannot be combined directly without normalization or another transformation.

After preprocessing, the values can be evaluated through multiple logic paths, models, or reference relationships. Each path may examine a different aspect of battery condition. One relationship may compare resistance with expected aging behavior, while another may evaluate capacity or charging response against reference data. The precise architecture could involve lookup matrices, rules, statistical relationships, or another model; the general diagnostic principle does not depend on assigning one particular algorithm to every implementation.

The separate results can then be combined through averaging and weighting to obtain an overall health estimate. Weighting matters because different applications place different demands on a battery. A battery used for high-current discharge may require greater emphasis on discharge capability and voltage stability. A standby battery may require closer attention to capacity retention and self-discharge. The appropriate weighting cannot be assumed to be the same for every application.

A useful processing sequence can be represented as follows:

  1. Measure the battery’s electrical and performance characteristics.
  2. Send the measurements to the diagnostic controller or analysis system.
  3. Normalize or otherwise transform the raw values into comparable variables.
  4. Evaluate the variables using several models, rules, or battery-specific reference relationships.
  5. Combine the resulting indicators using averaging and application-dependent weighting.
  6. Report an overall state-of-health estimate, together with any limitations or abnormal-condition flags supported by the system.

This approach can be more informative than a single resistance value, but it does not eliminate the need for controlled test conditions. Incorrect battery identification, poor contacts, unsuitable reference data, temperature differences, or an abnormal individual cell can all affect the output. The percentage should be treated as an estimate based on the system’s model and evidence, not as a direct physical measurement of remaining battery life.

Pack Interconnections Can Distort Resistance Measurements

A multi-cell nickel battery pack contains more than electrochemical cells. Its electrical path may include cell tabs, welded joints, bus bars, connectors, fuses, pressure contacts, wiring, and other mechanical links. A pack-level resistance measurement can therefore include the combined contribution of the cells and these interconnections.

This effect becomes more important as the number of cells and connections increases. The reference material draws attention to packs of roughly ten cells or more, but that should not be treated as a universal threshold. The significance of interconnection resistance depends on pack design, conductor dimensions, weld quality, connector condition, contact pressure, the measurement instrument, and the test signal.

Metal links also respond differently from electrochemical cells during an excitation-based diagnostic. A cell has electrochemical processes that vary with frequency, state of charge, temperature, and internal condition. A metal tab, weld, or connector primarily contributes an ohmic and connection-related component. If the diagnostic system interprets the complete response as though it came only from the cells, pack hardware can introduce an error into the estimated battery condition.

Possible sources of additional resistance include:

  • Inadequate or damaged welds
  • Corroded tabs, terminals, or connectors
  • Loose or contaminated contacts
  • High contact pressure variation between cells
  • Long or undersized conductors
  • Cracked interconnects or mechanically stressed joints
  • Poor assembly consistency across the pack

This pack-related contribution may not be revealed in the same way by a conventional capacity discharge. A discharge test primarily reports the delivered capacity under its defined load and cutoff conditions; it does not automatically identify every connection problem. A simple resistance check may also combine cell and interconnect effects without separating them. An excitation-based rapid test can add further interpretation error if its model does not adequately account for the pack architecture and test conditions.

When interpreting a pack-level result, record the physical construction and inspect the current path as well as the cells. Where possible, compare measurements at the cell level, across defined sections of the pack, or before and after checking suspect connections. The goal is to distinguish electrochemical aging from resistance introduced by assembly, corrosion, welding, or contact quality.

Cell-to-Cell Variation and the Limits of Pack-Level Results

Cells in a multi-cell pack do not necessarily age at the same rate. Differences in manufacturing, initial capacity, temperature exposure, charging, loading, self-discharge, and mechanical connection quality can cause cells to respond differently to the same diagnostic signal.

As a pack ages, the divergence between cells may increase. One cell may lose capacity faster, develop higher resistance, or self-discharge more quickly than the others. Another cell may remain comparatively healthy. The pack can continue to produce an apparently moderate combined result even though one member is approaching failure.

This creates an important limitation: an aggregate pack result is often an average or combined representation. It does not prove that every cell has the same condition. A pack-level state-of-health estimate can conceal a weak, abnormal, or failing cell, especially when the other cells dominate the measured response.

For maintenance and fault diagnosis, a pack result should therefore be treated as a screening result that may require follow-up. Useful follow-up can include:

  • Identifying and testing individual cells where the pack design permits it
  • Comparing cell voltages and resistance under consistent conditions
  • Checking for abnormal self-discharge
  • Performing a controlled capacity test on suspect cells or modules
  • Inspecting welds, tabs, connectors, and contact surfaces
  • Repeating measurements at a controlled temperature and known state of charge

The scope of this discussion is nickel-based rechargeable batteries, particularly NiCd and NiMH systems. Nickel batteries have electrical and electrochemical behavior that differs from lithium-ion and lead-acid batteries. A test method, resistance interpretation, health model, or failure criterion developed for one of those chemistries should not automatically be transferred to another.

Lithium-ion packs commonly rely on chemistry-specific limits, protection electronics, balancing information, and battery-management-system data. Lead-acid batteries have their own charging behavior, sulfation mechanisms, temperature effects, and conductance or load-test practices. For either chemistry, use testing guidance and reference data designed for that battery type. The same principle applies within the nickel family: NiCd and NiMH results should be interpreted with suitable references for the particular cell and application.
